Shimadzu PDA-7000 - Repair parts

xxi
Repair parts
No.
P/N
Part name
Notes
1
211-52482-91
Cable 15C
Spark stand – Sample holder
2
080-68536-01
Flowmeter F900
Spark stand
argon gas purge line
3
211-75818
Flow meter、RK1650
4
211-74517
Valve V1 Assy
5
211-74517-01
Valve V2 Assy
6
040-21333-57
Valve、2400L-B-N1-1/4
7
016-31330
Vinyl hose 9x2.5 CL (2MT)
Spark stand
argon gas exhaust line
8
211-51930
Argon gas bubbler
9
036-19003-33
O-ring 1A S42
Used in spark stand
10
036-12001
O-ring 1A G25
11
036-10341-12
O-ring R-LEP12
12
064-60774-02
Switch PB ABW110-G
START switch
13
064-60776-09
Switch PB ABW201-R
STOP switch
14
066-81601
Switch DPRI-01
Proximity sensor switch
Used for stand door and
excita-tion unit panel
*
1
15
202-46611-01
Lens assembly (Q1)
Condenser lens (quartz)
205-01583-01
Lens assembly (MgF
2
)
Condenser lens (MgF
2
)
16
211-74649-91
Ignition coil assembly
17
211-50467-01
Control gap electrode (Φ2mm)
18
042-60424-23
Fan 4710PS-20T-B30-B00
19
042-60934-13
Filter set 9450-M
(Filter set used for fan above)
20
211-74756-91
FET assembly
21
060-40917-12
Thyristor PK25GB-80
Excitation unit
22
072-06035-11
Fuse 600CF-5
23
072-01673-13
Fuse 3AG-312.500
24
065-80826-06
Relay MY4N AC200V
25
065-60648-11
Relay LY2N DC24V
26
065-60848-02
Relay LY4N DC24V
27
211-50828-92
Excitation unit control board
HPSG CONT PCB
28
211-50765-01
Cable 15A
Excitation unit – sample (–)
29
211-50765-02
Cable 15B
Excitation unit – electrode (+)
30
211-50797
Read-out unit power board DC PCB
31
211-50785
A/D converter board AD PCB
32
211-50794-92
Control circuit board CHECK PCB
Read-out unit
33
211-50791
Integrator board ITG PCB
34
211-50788
Negative HV power board HV PCB
35
211-72137-93
CPU cont. unit
SCSI control box
36
062-62104
Lamp H0857
Fatigue lamp
37
211-66527-91
Pirani tube filament
