Shimadzu PDA-7000 User Manual

1 Configuration and Function of the Instrument
1-3
1.1 Switch panel
Switch panel
① MAIN
Main power switch
Supplies power to the entire instrument.
② SOURCE
Excitation unit power switch
Supplies power to the excitation unit.
③ AIRCON
Temperature controller power
switch
Supplies power to the temperature
control system.
④ CONSOLE
Read-out unit power switch
Supplies power to the read-out and data
processor system.
⑤ TEMP
Temperature control display
Displays temperature of the spectrometer
system and set temperature.
⑥ PUMP
Power supply for pump
Supplies power to the vacuum pump.
⑦ AC IN
Main power
Accepts the power cable.
⑧
Grounding terminal
Accepts the grounding cable.
⑨ GAS IN
Gas flow entrance
Accepts the gas tube.
⑩ CPU I/O
Data processor system
Accepts the cable for data processor
system (bellows type tube)
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩
