1 Configuration and Function of the Instrument
1-2
1 Configuration and Function of the Instrument
The emission analysis is a method to carry out a quantitative analysis of elements
contained in a sample, by generating the optical emission by giving the sample electric and
thermal energy, and then measuring the intensity of the bright-line spectra peculiar to those
elements using the spectrometer.
The quantitative analysis for emission analysis is carried out by utilizing a proportional
relation existing within a certain range, between the content of an element and the intensity
of its spectral line.
The configuration of the instrument is shown in the figure below.
Configuration of PDA-7000
Read-out unit
Spectrometer
Excitation unit
Spark Stand
Data processor
Switch panel
