● Do not block the ventilation openings. Without proper heat dissipation and air circulation, the
internal components may overheat. This can result in product damage.
● Do not install near equipment that produces heat, for example amplifiers.
Personal Protective Equipment
During installation and rigging wear personal protective equipment in compliance with the national and
site-specific regulations.
4.3. Installation Site Requirements
● The device must be installed only indoors.
● The device can be placed on a flat surface or mounted to any kind of truss, with clamps and/or
M5/M10 screws for fixed installations.
● The maximum ambient temperature t
a
= 40 °C must never be exceeded.
● The relative humidity must not exceed 50 % with an ambient temperature of 40 °C.
4.4. Rigging
The device can be positioned on a flat surface or mounted to a truss or other rigging structure. Make sure
that all loads are within the pre-determined limits of the supporting structure.
To mount the device, follow the steps below:
Use clamps to attach the device to the supporting structure, as shown in Fig. 06 on page 13. Make
sure that the device cannot move freely.
02) Secure the device with a secondary suspension, for example a safety cable. Make sure that the
secondary suspension can hold 10 times the weight of the device. If possible, the secondary
suspension should be attached to a supporting structure independent of the primary suspension. Put
the safety cable through the safety eye (13), as shown in Fig. 06 on page 13. You can use the safety
cable supplied with the device.
03) It is also possible to mount the device with 4 x M5 screws. Drill holes in the wall, place the controller on
the wall and tighten the screws.
