SHOWTEC Pixel User Manual

46
Pixel Controller
Product code: 44510
PixelDot
7 Channels
7 CH
Function
Value
Setting
1
Master Dimmer
000–255
From low to high intensity (0–100 %)
2
Strobe
000–004
Strobe off
005–255
From low to high frequency
3
Red
000–255
From low to high intensity (0–100 %)
4
Green
000–255
From low to high intensity (0–100 %)
5
Blue
000–255
From low to high intensity (0–100 %)
6
Built-in
programs
000–015
Not functional
016–023
Program 1
024–031
Program 2
032–039
Program 3
040–047
Program 4
048–055
Program 5
056–063
Program 6
064–071
Program 7
072–079
Program 8
080–087
Program 9
088–095
Program 10
096–103
Program 11
104–111
Program 12
112–119
Program 13
120–127
Program 14
128–135
Program 15
136–143
Program 16
144–151
Program 17
152–159
Program 18
160–167
Program 19
168–175
Program 20
176–183
Program 21
184–191
Program 22
192–199
Program 23
200–207
Program 24
208–215
Program 25
216–223
Program 26
224–231
Program 27
232–239
Program 28
240–247
Program 29
248–255
Programs 1–29
7
Program speed
000–255
From slow to fast
Note: Make sure that the Master Dimmer channel is open in order to see the light output.
Note: Make sure that the Built-in Programs channel is closed in order to use the Red, Green and
Blue channels.

SHOWTEC Pixel Specifications

General

Channels	512
Weight	0.2 kg
DMX Channels	512
Control Protocol	DMX512
DMX Connectors	3-pin XLR
Storage Temperature	-20°C to 60°C
