This device is intended for professional use as a pixel controller. It is suitable only for indoor installation. This
device is not suitable for households and for general lighting.
Any other use, not mentioned under intended use, is regarded as non-intended and incorrect use.
Before connecting the device to the power supply, make sure that the current, voltage and frequency
match the input voltage, current and frequency specified on the information label on the device.
Control Modes
The Pixel Controller supports the following control modes:
● Stand-alone: Auto, Manual
● Master/Slave
● DMX-512 See 6.7. DMX Channels on pages 33–51 for more information
● Art-Net, Kling-Net See 6.7. DMX Channels on pages 33–51 for more information
For more information about how to connect the devices, refer to 5. Setup on pages 14–21.
To operate the device manually as a stand-alone device or in a master/slave setup:
Adjust the levels for red, green, blue and strobe in Manual menu. See 6.6.3.8. Manual on page 31 for
more information.
To run one of the built-in programs in auto operation mode without a DMX controller:
Select one of the 30 built-in programs in Auto menu. See 6.6.3.7. Auto on page 30 for more
information.
Set the speed of the built-in chase in Auto menu. See 6.6.3.7. Auto on page 30 for more information.
To operate the device with a DMX controller:
Set the DMX starting address of the device in the DMX Address menu. See 5.2.5. DMX Addressing on
page 18 and 6.6.1. DMX Address on page 25.
02) Select the DMX channel mode. See 6.6.3.3. DMX on page 28 for more information. See 6.7. DMX
Channels on pages 33–51 for complete overview of all DMX channels.
