SHOWTEC Pixel User Manual

34
Pixel Controller
Product code: 44510
120, 240, 360, 480 Channels
120
CH
240
CH
360
CH
480
CH
Function
Value
Setting
1
1
1
1
Red (pixel 1)
000–255
From low to high intensity (0–100 %)
2
2
2
2
Green (pixel 1)
000–255
From low to high intensity (0–100 %)
3
3
3
3
Blue (pixel 1)
000–255
From low to high intensity (0–100 %)
4
4
4
4
Red (pixel 2)
000–255
From low to high intensity (0–100 %)
5
5
5
5
Green (pixel 2)
000–255
From low to high intensity (0–100 %)
6
6
6
6
Blue (pixel 2)
000–255
From low to high intensity (0–100 %)
7
7
7
7
Red (pixel 3)
000–255
From low to high intensity (0–100 %)
8
8
8
8
Green (pixel 3)
000–255
From low to high intensity (0–100 %)
9
9
9
9
Blue (pixel 3)
000–255
From low to high intensity (0–100 %)
10
10
10
10
Red (pixel 4)
000–255
From low to high intensity (0–100 %)
11
11
11
11
Green (pixel 4)
000–255
From low to high intensity (0–100 %)
12
12
12
12
Blue (pixel 4)
000–255
From low to high intensity (0–100 %)
…
…
…
…
118
118
118
118
Red (pixel 40)
000–255
From low to high intensity (0–100 %)
119
119
119
119
Green (pixel 40)
000–255
From low to high intensity (0–100 %)
120
120
120
120
Blue (pixel 40)
000–255
From low to high intensity (0–100 %)
…
…
…
238
238
238
Red (pixel 80)
000–255
From low to high intensity (0–100 %)
239
239
239
Green (pixel 80)
000–255
From low to high intensity (0–100 %)
240
240
240
Blue (pixel 80)
000–255
From low to high intensity (0–100 %)
…
…
358
358
Red (pixel 120)
000–255
From low to high intensity (0–100 %)
359
359
Green (pixel 120)
000–255
From low to high intensity (0–100 %)
360
360
Blue (pixel 120)
000–255
From low to high intensity (0–100 %)
…
478
Red (pixel 160)
000–255
From low to high intensity (0–100 %)
479
Green (pixel 160)
000–255
From low to high intensity (0–100 %)
480
Blue (pixel 160)
000–255
From low to high intensity (0–100 %)

SHOWTEC Pixel Specifications

General

Channels	512
Weight	0.2 kg
DMX Channels	512
Control Protocol	DMX512
DMX Connectors	3-pin XLR
Storage Temperature	-20°C to 60°C
