SHOWTEC Pixel User Manual

25
Pixel Controller
Product code: 44510
Main Menu Options
The main menu has the following options:
DMX Address
Network Settings
Pixel Type / Set Output / DMX / Art-Net / Kling-Net / Slave / Auto / Manual
Signal Hold / Pixel Reverse / Screen Timeout / Screen Brightness / Software Version /
Invert Display / Factory Reset
Press the UP/DOWN buttons to navigate through the main menu.
Press the ENTER button to open the submenus.
Press the MENU button to return to the previous screen.
DMX Address
In this menu you can set the DMX starting address of the device.
01) While in main menu, press the UP/DOWN buttons to select .
02) Press the ENTER button to confirm and open this menu.
03) Press the UP/DOWN buttons to select the DMX starting address. The selection range is 001–512.
Press the ENTER button to confirm the selection.

SHOWTEC Pixel Specifications

General

Channels	512
Weight	0.2 kg
DMX Channels	512
Control Protocol	DMX512
DMX Connectors	3-pin XLR
Storage Temperature	-20°C to 60°C
