SHOWTEC Pixel User Manual

47
Pixel Controller
Product code: 44510
30, 60, 90, 120 Channels
30
CH
60
CH
90
CH
120
CH
Function
Value
Setting
1
1
1
1
Red (PixelDot 1)
000–255
From low to high intensity (0–100 %)
2
2
2
2
Green (PixelDot 1)
000–255
From low to high intensity (0–100 %)
3
3
3
3
Blue (PixelDot 1)
000–255
From low to high intensity (0–100 %)
4
4
4
4
Red (PixelDot 2)
000–255
From low to high intensity (0–100 %)
5
5
5
5
Green (PixelDot 2)
000–255
From low to high intensity (0–100 %)
6
6
6
6
Blue (PixelDot 2)
000–255
From low to high intensity (0–100 %)
7
7
7
7
Red (PixelDot 3)
000–255
From low to high intensity (0–100 %)
8
8
8
8
Green (PixelDot 3)
000–255
From low to high intensity (0–100 %)
9
9
9
9
Blue (PixelDot 3)
000–255
From low to high intensity (0–100 %)
…
…
…
…
28
28
28
28
Red (PixelDot 10)
000–255
From low to high intensity (0–100 %)
29
29
29
29
Green (PixelDot 10)
000–255
From low to high intensity (0–100 %)
30
30
30
30
Blue (PixelDot 10)
000–255
From low to high intensity (0–100 %)
…
…
…
000–255
From low to high intensity (0–100 %)
58
58
58
Red (PixelDot 20)
000–255
From low to high intensity (0–100 %)
59
59
59
Green (PixelDot 20)
000–255
From low to high intensity (0–100 %)
60
60
60
Blue (PixelDot 20)
000–255
From low to high intensity (0–100 %)
…
…
88
88
Red (PixelDot 30)
000–255
From low to high intensity (0–100 %)
89
89
Green (PixelDot 30)
000–255
From low to high intensity (0–100 %)
90
90
Blue (PixelDot 30)
000–255
From low to high intensity (0–100 %)
…
118
Red (PixelDot 40)
000–255
From low to high intensity (0–100 %)
119
Green (PixelDot 40)
000–255
From low to high intensity (0–100 %)
120
Blue (PixelDot 40)
000–255
From low to high intensity (0–100 %)
Note: The 30-channel is available when 10xPixDOT option was selected in the menu.
Note: The 60-channel is available when 20xPixDOT option was selected in the menu.
Note: The 90-channel is available when 30xPixDOT option was selected in the menu.
Note: The 120-channel is available when 40xPixDOT option was selected in the menu.
See 6.6.3.2. Set Output and 6.6.3.3. DMX on page 28 for more information.

SHOWTEC Pixel Specifications

General

Channels	512
Weight	0.2 kg
DMX Channels	512
Control Protocol	DMX512
DMX Connectors	3-pin XLR
Storage Temperature	-20°C to 60°C
