Scanning frequencies
0
1 000
900
800
700
600
400
500
c: 0.20 mm (7.9 mil)
a: 0.10 mm (3.9 mil) b: 0.15 mm (5.9 mil)
50
(1.97)
40
(1.57)
30
(1.18)
20
(0.79)
10
(0.39)
60
(2.36)
70
(2.76)
80
(3.15)
90
(3.54)
100
(3.94)
Scanning frequency in Hz 1
Reading distance in mm (inch) 2
Code resolution 3
a
b
c
Figure 34: Characteristic curve field for scan frequency for CLV612, short range, front viewing
window
1
Scanning frequency in Hz
2
Reading distance in mm (inch)
3
Resolution
NOTE
Correction of reading distance for devices with side viewing window:
At all scan frequencies, the values for the reading distance shift towards the
viewing window in each case by 16 mm (reduction of the reading distance).
TECHNICAL DATA 12
8017840/19OF/2021-10-28 | SICK O P E R A T I N G I N S T R U C T I O N S | CLV61x
69
Subject to change without notice
