Scanning frequencies
0 50 100 150 200 250 300 350 400
(1.97) (3.94) (5.91) (7.87) (9.84) (11.81) (13.78) (15.75)
900
800
700
600
500
400
Resolution 3
Scanning frequency in Hz 1
Reading distance in mm (inch) 2
b: 0.50 mm (19.7 mil)a: 0.35 mm (13.8 mil)
a
b
1 000
Figure 36: Characteristic curve field for CLV615 scanning frequency, Long Range, side viewing
window
1
Scanning frequency in Hz
2
Reading distance in mm (inch)
3
Resolution
TECHNICAL DATA 12
