Table 10: Technical specifications, receiver
Minimum Typical Maximum
Output signal switching devices
(OS
SDs)
2 PNP semiconductors, short-circuit protected
1)
, cross-
circuit monitored
Response time "Response time", page 59
Duration of OFF state 100 ms
Switch-on delay 3 × response
t
ime
ON state, switching voltage HIGH
(U
rms
)
2)
U
V
–2.25 V 24 V U
V
OFF state, switching voltage LOW
2)
3)
0 V 0 V 2.0 V
Current-carrying capacity of the
O
SSDs
300 mA each
Leakage current of the OSSDs 2 mA each
Load capacity 2.2 µF
4)
Load inductance 2.2 H
Test pulse data
5)
Test pulse range 150 µs
6)
300 µs
6)
Test pulse rate 3
1
/s 5
1
/s 10
1
/s
Permissible conductor resistance
between device and load
7)
2.5 Ω
Supply cable
8)
1 Ω
1)
Applies to the voltage range between -30 V and +30 V.
2)
According to IEC 61131-2.
3)
The specified values are the switching voltage passed to the safety light curtain. If higher voltages are
im
pressed from the outside, the maximum value of 2.0 V may be exceeded.
4)
Applies to devices marked “(Rev. 1)” on the “Ident No.” type label entry. For devices not marked “(Rev.
1)”, the following applies: Load capacity (maximum) = 30 nF.
5)
When active, the outputs are tested cyclically (brief LOW). When selecting the downstream controllers,
make sure that the test signals do not result in deactivation when using the above parameters.
6)
Applies to devices marked “(Rev. 1)” on the “Ident No.” type label entry. For devices not marked “(Rev.
1)”, the following applies: Test pulse width (typical) = 300 µs; test pulse width (maximum) = 350 µs.
7)
Make sure to limit the individual conductor resistance to the downstream controller to this value to
ensure that a cross-circuit between the outputs is safely detected. (Also observe IEC 60204-1.)
8)
The supply cable must not be used to connect other loads with the exception of the sender.
Table 11: Operating data
Minimum Typical Maximum
Connection Plug, M12, 5-pin
Length of cable
1)
e
.g. wire cross-section 0.34 mm²,
copper cable
e.g. wire cross-section 0.5 mm²,
copper cable
50 m
15 m
30 m
Ambient operating temperature
2)
3)
-30°C +55°C
Air humidity (non-condensing) 15% 95%
Storage temperature -30°C +70°C
Housing cross section 31 mm × 34 mm, plus bracket, see "Dimensional dr
aw‐
ings", page 61
Vibration resistance
4)
5 g, 10 Hz … 55 Hz (IEC 60068-2-6)
12 TECHNICAL DATA
58
O P E R A T I N G I N S T R U C T I O N S | deTec4 Core 8014253/ZOH3/2017-08-04 | SICK
Subject to change without notice
