SICK deTec4 Core User Manual

13 Ordering information
13.1 Scope of delivery
Scope of delivery, sender
•
S
ender
Scope of delivery, receiver
•
Receiver
•
Test rod with diameter corresponding to the resolution of the safety light curtain
•
Safety note
•
Mounting instructions
•
Operating instructions for download: www.sick.com
13.2 Ordering information deTec4 Core
Table 17: Ordering information deTec4 Core, resolution 14 mm
Protective field
height in mm
s S
ender r Receiver
Part number Type code Part number Type code
300 1211450 C4C-SA03010A10000 1211463 C4C-EA03010A10000
450 1211469 C4C-SA04510A10000 1211470 C4C-EA04510A10000
600 1211471 C4C-SA06010A10000 1211472 C4C-EA06010A10000
750 1211473 C4C-SA07510A10000 1211474 C4C-EA07510A10000
900 1211475 C4C-SA09010A10000 1211515 C4C-EA09010A10000
1050 1211476 C4C-SA10510A10000 1211477 C4C-EA10510A10000
1200 1211478 C4C-SA12010A10000 1211479 C4C-EA12010A10000
1350 1211480 C4C-SA13510A10000 1211481 C4C-EA13510A10000
1500 1211482 C4C-SA15010A10000 1211483 C4C-EA15010A10000
1650 1211484 C4C-SA16510A10000 1211485 C4C-EA16510A10000
1800 1211486 C4C-SA18010A10000 1211487 C4C-EA18010A10000
1950 1211488 C4C-SA19510A10000 1211489 C4C-EA19510A10000
2100 1211490 C4C-SA21010A10000 1211491 C4C-EA21010A10000
Table 18: Ordering information deTec4 Core, resolution 30 mm
Protective field
hei
ght in mm
s S
ender r Receiver
Part number Type code Part number Type code
300 1211462 C4C-SA03030A10000 1211464 C4C-EA03030A10000
450 1211492 C4C-SA04530A10000 1211493 C4C-EA04530A10000
600 1211494 C4C-SA06030A10000 1211495 C4C-EA06030A10000
750 1211496 C4C-SA07530A10000 1211497 C4C-EA07530A10000
900 1211498 C4C-SA09030A10000 1211516 C4C-EA09030A10000
1050 1211499 C4C-SA10530A10000 1211500 C4C-EA10530A10000
1200 1211501 C4C-SA12030A10000 1211502 C4C-EA12030A10000
1350 1211503 C4C-SA13530A10000 1211504 C4C-EA13530A10000
1500 1211505 C4C-SA15030A10000 1211506 C4C-EA15030A10000
1650 1211507 C4C-SA16530A10000 1211508 C4C-EA16530A10000
1800 1211509 C4C-SA18030A10000 1211510 C4C-EA18030A10000
1950 1211511 C4C-SA19530A10000 1211512 C4C-EA19530A10000
2100 1211513 C4C-SA21030A10000 1211514 C4C-EA21030A10000
ORDERING INFORMATION 13
8014253/ZOH3/2017-08-04 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core
63
Subject to change without notice

SICK deTec4 Core Specifications

General

Enclosure rating	IP65, IP67
Operating voltage	24 V DC
Resolution	14 mm
Supply voltage Uv	24 V DC
Light source	Infrared LED
Connection type	M12 connector
