SICK deTec4 Core

Part Type code Part number
Female connector, straight, 20 m c
able, open
end
DOL-1205-G20MC 6050247
Female connector, straight, 30 m cable, open
end
DOL-1205-G30MC 6050248
Female connector, angled, 2 m cable, open
end
DOL-1205-W02MC 6025909
Female connector, angled, 5 m cable, open
end
DOL-1205-W05MC 6025910
Female connector, angled, 10 m c
able, open
end
DOL-1205-W10MC 6025911
Table 23: Ordering information, connection cable (replacement of existing devices)
2)
Part Type code Part number
Connection cable, M12, 5-pin to M12, 8-pin DSL-1285GM25034KM1 2070987
Connection cable, M12, 5-pin to M26, 7-pin DSL-6187GM25034KM1 2070988
Connection cable, M12, 5-pin to M26, 12-pin DSL-6182GM25034KM1 2070989
Table 24: Distributor ordering information
Part Type code Part number
T distributor, 5-pin DSC-1205T000025KM0 6030664
Table 25: Resistance terminal ordering information
Part Part number
Resistance terminal, 2.15 kΩ 2073807
Table 26: Ordering information for power supply
Part Type code Part number
Output 24 V DC, 50 W (2.1 A), voltage supply
NE
C Class 2, SELV, PELV, input
120 V … 240 V AC
PS50WE24V 7028789
Output 24 V DC, 95 W (3.9 A), voltage supply
NE
C Class 2, SELV, PELV, input
100 V … 120 V/220 V … 240 V AC
PS95WE24V 7028790
14.5 Alignment aid
Table 27: Alignment aid ordering information
Part Part number
Laser alignment aid AR60 1015741
Adapter 4070854
14.6 Deflector mirrors
14.6.1 Function and use
Overview
D
eflector mirrors can be used to shape the protective field to secure hazardous points
from multiple sides using a single safety light curtain.
2)
Ambient operating temperature: Down to –30 °C with fixed installation
14 A
CCESSORIES
68
