SICK deTec4 Core

5 Mounting
5.1 Safety
Important information
DANGER
D
angerous state of the machine
b
Make sure that the dangerous state of the machine is (and remains) switched off
during mounting, electrical installation, and commissioning.
b
Make sure that the outputs of the safety light curtain do not affect the machine
during mounting, electrical installation, and commissioning.
DANGER
H
azard due to lack of effectiveness of the protective device
If unsuitable brackets are used or if subjected to excessive vibrations, the device may
become detached or damaged.
Persons and parts of the body to be protected may not be recognized in case of non-
observance.
b
Only use SICK-approved brackets for mounting.
b
Take appropriate measures for vibration damping if vibration and shock specifica‐
tions exceed the values and test conditions specified in the data sheet.
DANGER
H
azard due to lack of effectiveness of the protective device
Persons and parts of the body to be protected may not be recognized in case of non-
observance.
b
Do not do repair work on device components.
b
Do not make changes to or manipulate device components.
b
Apart from the procedures described in this document, the device components
must not be opened.
NOTE
Mount t
he device in the following order.
Prerequisites
T
he construction of the safety light curtain has been correctly executed.
Further topics
•
"Design", page 17
•
"Technical data", page 57
5.2 Unpacking
Approach
1.
Check the components for completeness and integrity for all parts.
2. Please contact your respective SICK subsidiary should you have any complaints.
Further topics
•
"Scope of delivery", page 63
MOUNTING 5
