Figure 23: Upgrade bracket, installation version A
C4000, C2000
deTec4
B
B
2071021
2019649
2019659
Figure 24: Upgrade bracket, installation version B
MOUNTING 5
8014253/ZOH3/2017-08-04 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core
39
Subject to change without notice
