SICK deTec4 Core User Manual

Mirror length in mm Max. protective field
hei
ght in mm
Type code Part number
940 900 PNS125-094 1019429
1090 1050 PNS125-109 1019430
1240 1200 PNS125-124 1019431
1390 1350 PNS125-139 1019432
1540 1500 PNS125-154 1019433
1690 1650 PNS125-169 1019434
1840 1800 PNS125-184 1019435
14.7 Mirror columns and device columns
14.7.1 Mirror columns
Table 31: Ordering information for mirror columns
Column height Mirror length Type code Part number
1281.5 mm 1082 mm PM3C13-00030000 1043453
1569 mm 1382 mm PM3C15-00030000 1077525
1716.5 mm 1532 mm PM3C17-00030000 1043454
2016.5 mm 1682 mm PM3C19-00030000 1043455
2216.5 mm 1832 mm PM3C20-00030000 1043456
Complementary information
Observe the information on deflector mirrors, particularly on changing the scanning
range.
Further topics
•
"Deflector mirrors", page 68
14.7.2 Device columns
Table 32: Ordering information for device columns
Column height Max. installation
len
gth
Type code Part number
985 mm 965 mm PU3H96-00000000 2045490
1185 mm 1165 mm PU3H11-00000000 2045641
1285 mm 1265 mm PU3H13-00000000 2045642
1570 mm 1550 mm PU3H15-00000000 2068813
1740 mm 1720 mm PU3H17-00000000 2045643
2040 mm 2020 mm PU3H21-00000000 2045644
2270 mm 2250 mm PU3H22-00000000 2045645
2420 mm 2400 mm PU3H24-00000000 2045646
14.8 Cleaning agent
Table 33: Cleaning agent ordering information
Part Part number
Anti-static plastic cleaner 5600006
Lens cloth 4003353
ACCESSORIES 14
8014253/ZOH3/2017-08-04 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core
71
Subject to change without notice

SICK deTec4 Core Specifications

General

Enclosure rating	IP65, IP67
Operating voltage	24 V DC
Resolution	14 mm
Supply voltage Uv	24 V DC
Light source	Infrared LED
Connection type	M12 connector
