Sender indicators
Resolution 30 mmResolution 14 mm
ERR
PWR
ERR
PWR
Figure 2: Sender indicators
T
wo light emitting diodes on the sender indicate the operational status:
Position LED color Indication Labeling
1
Yellow Status indicator PWR
2
Red Fault indicator ERR
Complete overview of the LED statuses and their meanings: see "Dia
gnostic LEDs",
page 53.
