Protective field height, nominal in mm Protective field height, effective = dimension L
in mm
1)
1950 1962
2100 2112
1)
The effective protective field corresponds to the entire length of the housing. The test object defined in
t
he standard IEC 61496-1 is recognized over the entire length of the housing. The limits of the protective
field are identical to ends of the housing.
12 T
ECHNICAL DATA
62
O P E R A T I N G I N S T R U C T I O N S | deTec4 Core 8014253/ZOH3/2017-08-04 | SICK
Subject to change without notice

SICK deTec4 Core Specifications

General

Enclosure rating	IP65, IP67
Operating voltage	24 V DC
Resolution	14 mm
Supply voltage Uv	24 V DC
Light source	Infrared LED
Connection type	M12 connector
