Table 5: Procedure phases during manual adjustment
Actual state Internal function
Stop Function idle
Test gas Wait for flush time to elapse (after switching to test gas)
Measuring Determine measured values with the test gas
Calculate Calculate mean value from measuring time, calculate devia‐
tion from setpoint, adapt adjustment
Sample gas Wait for flush time to elapse (after switching to sample gas)
Table 6: Information in menu Manual adjustment during the procedure
Identifier Significance
Actual state Part of the procedure running (see table 5, page 42)
Meas. value Current measured value of component
Actual countdown timer (SCCDGi) Name of countdown timer running
Remaining time Remaining time of countdown timer running
