Error

code

Name DS402

(error

code)

Error reaction Config-

urable

via para-

meters

57 Output stage - Short circuit 0x2340 Immediate switch-off No

57-1 Output stage - Short circuit FPGA phase U 0x2341 Immediate switch-off No

57-2 Output stage - Short circuit FPGA phase V 0x2342 Immediate switch-off No

57-3 Output stage - Short circuit FPGA phase W 0x2343 Immediate switch-off No

57-4 Output stage - Short circuit HW 0x2344 Immediate switch-off No

57-5 Output stage - Short circuit HW OL phase U 0x2345 Immediate switch-off No

57-6 Output stage - Short circuit HW OL phase V 0x2346 Immediate switch-off No

57-7 Output stage - Short circuit HW OL phase W 0x2347 Immediate switch-off No

58 Output stage - Error 0x5410 Immediate switch-off No

58-1 Output stage - UVLO phase U 0x5411 Immediate switch-off No

58-2 Output stage - UVLO phase V 0x5412 Immediate switch-off No

58-3 Output stage - UVLO phase W 0x5413 Immediate switch-off No

59 Undervoltage in DC link 0x3220 Immediate switch-off No

59-1 Undervoltage in DC link - Power output stage 0x3221 Immediate switch-off No

59-2 Undervoltage in DC link - Power supply unit 0x3222 Immediate switch-off No

60 Overvoltage in DC link 0x3210 Immediate switch-off No

60-1 Overvoltage in DC link - Power output stage 0x3211 Immediate switch-off No

60-2 Overvoltage in DC link - Power supply unit 0x3212 Immediate switch-off No

60-3 Overvoltage neutral point - Power output stage 0x3213 Immediate switch-off No

61 Reserved

62 Configuration error 0x6080 Coast to standstill No

62-1 Device configuration 0x6081 Coast to standstill No

63 System error - Type plate 0x6170 Coast to standstill No

63-1 System error - RTOS 0x6171 Coast to standstill No

63-2 System error - FPGA 0x6172 Coast to standstill No

63-3 System error - STM / analog front end 0x6173 Coast to standstill No

63-4 System error - time basis 0x6174 Coast to standstill No

63-5 System error - User parameters 0x6175 Coast to standstill No

63-6 System error - Error memory 0x6176 Coast to standstill No

63-7 System error - I²C 0x6177 Coast to standstill No

63-8 System error - Device database 0x6178 Coast to standstill No

63-9 System error - FPGA synchronization 0x6179 Coast to standstill No

64 CPU - Program error - Division by zero 0x6180 Coast to standstill No

64-1 CPU - Program error - Unaligned memory access 0x6181 Coast to standstill No

64-2 CPU - Program error - Coprocessor access not possible 0x6182 Coast to standstill No

64-3 CPU - Program error - Illegal EXC_RETURN 0x6183 Coast to standstill No

64-4 CPU - Program error - Illegal use of EPSR 0x6184 Coast to standstill No

64-5 CPU - Program error - Undefined command 0x6185 Coast to standstill No

64-6 CPU - Bus error - Valid error address in BFAR 0x6186 Coast to standstill No

64-7 CPU - Bus error - Stacking error for exception entry 0x6187 Coast to standstill No

64-8 CPU - Bus error - Unstacking error for exception entry 0x6188 Coast to standstill No

64-9 CPU - Bus error - Imprecise data bus error 0x6189 Coast to standstill No

64-10 CPU - Bus error– Precise data bus error 0x618A Coast to standstill No

64-11 CPU - Bus error - Error on prefetching instruction 0x618B Coast to standstill No

64-12 CPU - Memory error - Valid error address in MMFAR 0x618C Coast to standstill No

64-13 CPU - Memory error - Stacking error by ARM MPU 0x618D Coast to standstill No

64-14 CPU - Memory error - Unstacking error by ARM MPU 0x618E Coast to standstill No

64-15 CPU - Memory error - Instr fetch from protected location 0x618F Coast to standstill No

Tab. 9: Error messages of SD4x series

61Drive Amplifier SD4B - Hardware Description

SD4x Drive Messages
