SD4x Drive Messages

Error

code

Name DS402

(error

code)

Error reaction Config-

urable

via para-

meters

34-15 Feedback 1 - Error 15 0x732F Coast to standstill or braking Yes

35 Feedback 2 - Monitoring 0x7380 Coast to standstill or brak-

ing

Yes

35-1 Feedback 2 - Track A not OK 0x7381 Coast to standstill or braking Yes

35-2 Feedback 2 - Track B not OK 0x7382 Coast to standstill or braking Yes

35-3 Feedback 2 - Track N not OK 0x7383 Coast to standstill or braking Yes

35-4 Feedback 2 - Encoder failure 0x7384 Coast to standstill or braking Yes

35-5 Feedback 2 - Evaluation error 0x7385 Coast to standstill or braking Yes

35-6 Feedback 2 - Short circuit 0x7386 Coast to standstill or braking Yes

35-7 Feedback 2 - Input amplitude too low 0x7387 Coast to standstill or braking Yes

35-8 Feedback 2 - Input amplitude too high 0x7388 Coast to standstill or braking Yes

35-9 Feedback 2 - CRC1 error 0x7389 Coast to standstill or braking Yes

35-10 Feedback 2 - Error 10 0x738A Coast to standstill or braking Yes

35-11 Feedback 2 - Error 11 0x738B Coast to standstill or braking Yes

35-12 Feedback 2 - Error 12 0x738C Coast to standstill or braking Yes

35-13 Feedback 2 - Error 13 0x738D Coast to standstill or braking Yes

35-14 Feedback 2 - Error 14 0x738E Coast to standstill or braking Yes

35-15 Feedback 2 - Error 15 0x738F Coast to standstill or braking Yes

36 to 38 Reserved

39 Ballast circuit - Overtemperature 0x4510 Immediate switch-off No

40 Ballast circuit - I²t 0x7115 Immediate switch-off No

41 Ballast circuit - Overcurrent 0x7112 Immediate switch-off No

42 Reserved

43 DC/DC converters - Overtemperature 0x4610 Immediate switch-off No

44 DC/DC converters - I²t 0x71C0 Immediate switch-off No

45 DC/DC converters - Overcurrent 0x71D0 Immediate switch-off No

46 Reserved

47 Power supply unit load - I²t 0x2180 Immediate switch-off Yes

47-1 Power supply unit load - Bus ripple too high 0x2181 Immediate switch-off Yes

48 Power supply unit - Mains failure with active output

stage

0x3130 Braking Yes

48-1 Power supply unit - Phase failure L1 with active output

stage

0x3131 Braking Yes

48-2 Power supply unit - Phase failure L2 with active output

stage

0x3132 Braking Yes

48-3 Power supply unit - Phase failure L3 with active output

stage

0x3133 Braking Yes

49 Power supply unit - Overtemperature 0x4410 Immediate switch-off Yes

50 Power supply unit - Error in external power supply unit 0x3280 Immediate switch-off No

51 Power supply unit - Charge monitoring 0x3230 Immediate switch-off No

51-1 Power supply unit - Charge monitoring - Short circuit 0x3231 Immediate switch-off No

51-2 Power supply unit - Charge monitoring - Overvoltage 0x3232 Immediate switch-off No

51-3 Power supply unit - Charge monitoring - Zero point error 0x3233 Immediate switch-off No

52 Error supply voltage 0x5110 Immediate switch-off No

52-1 Error supply voltage 15 V 0x5111 Immediate switch-off No

52-2 Error supply voltage 24 V 0x5112 Immediate switch-off No

52-3 Error supply voltage 5 V 0x5113 Immediate switch-off No

53 Reserved

54 Output stage - I²t 0x2311 Immediate switch-off Yes

55 Output stage - Overtemperature 0x4210 Immediate switch-off Yes

55-1 Output stage - Overtemperature phase U 0x4211 Immediate switch-off Yes

55-2 Output stage - Overtemperature phase V 0x4212 Immediate switch-off Yes

55-3 Output stage - Overtemperature phase W 0x4213 Immediate switch-off Yes

56 Output stage - Short to ground 0x2330 Immediate switch-off No

Tab. 9: Error messages of SD4x series

60 Drive Amplifier SD4B - Hardware Description
