Siemens 3RS2

Byte.Bit Description
50.0 ... 51.7 Current input 4 ... 20 mA - minimum range
1)
Type: INT
Default: 40
Selected unit °C / °F %
Min: -200 0
Max: 9999 150
52.0 ... 53.7 Current input 4 ... 20 mA - maximum range
1)
Type: INT
Default: 80
Selected unit °C / °F %
Min: -200 0
Max: 9999 150
54.0 ... 55.7 O󹪜set Sensor 1
Type: INT
Default: 0
Min: -99
Max: 99
56.0 ... 57.7 O󹪜set Sensor 2
Type: INT
Default: 0
Min: -99
Max: 99
58.0 ... 59.7 O󹪜set Sensor 3
Type: INT
Default: 0
Min: -99
Max: 99
60.0 ... 61.7 O󹪜set current input 4 ... 20 mA
Type: INT
Default: 0
Min: -10.0 mA / - 99 °C / °F
Max: 10.0 mA / 99 °C / °F
Reading always returns 0
62.0 ... 63.7 Comparison measuring point in °C / °F
Type: INT
Default: 0
Min: -25 °C / -13 °F
Max: 80 °C / 176 °F
Reading always returns 0
64.0 Eco mode
Default: [1]
[0]: disabled
[1]: enabled
Process data and data sets
16.8 Data set 131 - parameters
3RS2 temperature monitoring relay
Equipment Manual, 02/2022, A5E42462552002A/RS-AB/002 111
