Description
Cable plugs for single cable connection (interface type A)
Cable type Cable plug
Make Ser.
no.
Type Plug version
G/W
1
Conductor
cross-
section
[mm
2
]
Design
Thermoplastic-insulated cables ≤ 12 kV according to IEC / EN 60502-2 / VDE 0276-620
1-core cable, PE- and
XLPE-insulated
N2YSY (Cu) and
N2XSY (Cu)
or
NA2YSY (Al) and
NA2XSY (Al)
Nexans 1 158LR W 16...120 Screened; with capacitive measuring point
2 152SR G 95...120 Screened; with capacitive measuring point
nkt cables 3 EASW 10 / 250, size 2 W 25...95 Screened; option: with metal housing or
capacitive measuring point
4 EASG 10 / 250, size 2 G 25...95 Screened; option: with capacitive
measuring point
5 CE 24 – 250 W 95...120 Screened; option: with metal housing or
capacitive measuring point
Südkabel 6 SEHDG 11.1 G 25...120 Screened; option: with metal housing
7 SEW 12 W 25...120 Screened; option: with metal housing
Cooper Power
Systems
8 DE 250 – R-C W 16...120 Screened
9 DS 250 – R-C G 16...120 Screened
Prysmian Kabel
und Systeme
(Pirelli Elektrik)
10 FMCE-250 W 25...120 Screened
3M Germany 11 93-EE 605-2 / -95 W 25...95 Screened; option: with metal housing
12 93-EE 600-2 / xx G 25...150 Screened; option: with metal housing
TE Connectivity 13 RSSS 52xx G 25...95 Screened; with capacitive measuring point
14 RSES 52xx-R W 25...120 Screened; with capacitive measuring point
Thermoplastic-insulated cables 15 / 17.5 / 24 kV according to IEC / EN 60502-2 / VDE 0276-620
1-core cable, PE- and
XLPE-insulated
N2YSY (Cu) and N2XSY
(Cu)
or
NA2YSY (Al) and
NA2XSY (Al)
Nexans 15 K158LR W 16...120 Screened; with capacitive measuring point
16 K152SR G 25...120 Screened; with capacitive measuring point
nkt cables 17 EASG 20 / 250 G 25...95 Screened; option: with metal housing
18 CE 24 – 250 W 25...95 Screened; option: with metal housing or
capacitive measuring point
Südkabel 19 SEHDG 21.1 G 25...70 Screened; option: with metal housing
20 SEW 24 W 25...95 Screened; option: with metal housing
Cooper Power
Systems
21 DE 250 – R-C W 16...120 Screened
22 DS 250 – R-C G 16...120 Screened
Prysmian Kabel
und Systeme
(Pirelli Elektrik)
23 FMCE-250 W 25...120 Screened
3M Germany 24 93-EE 605-2 / -95 W 25...95 Screened; option: with metal housing
25 93-EE 600-2 / xx G 25...150 Screened; option: with metal housing
TE Connectivity 26 RSSS 52xx G 16...70 Screened; with capacitive measuring point
27 RSES 52xx-R W 16...120 Screened; with capacitive measuring point
1
G = Straight cable plug, W = Cable elbow plug
