Appendix D On-screen Controls
Instructions for Use D - 37
Flag Flag
Activates or deactivates a flag mark at the top of the selected image(s). The flag marker is
visible every time you review the image on the review screen.
Note: For systems without a touch screen, the selection is assigned to a button:
Copy to Film
Note: Multiple-frame images, such as clips and volumes, cannot be printed or copied to the
filming screen.
Copies the selected image(s) to the filming screen for printing.
Note: For systems without a touch screen, the selection is assigned to a soft key.
Delete
Activates or deactivates a deletion mark at the top of a selected image to indicate that the
image is tagged for deletion.
For active exams, the system deletes the tagged images from the patient study when you end
the examination. For previously saved exams, the system deletes the tagged images when
you end the review session.
For active exams, if the selected image displays a stress echo icon, all stress echo images are
marked for deletion.
Note: For systems without a touch screen, the selection is assigned to a soft key.
Selected Indicates the number of currently selected images.
Indicates the number of images copied to the filming screen.
Indicates the number of images that are tagged for deletion.
Indicates the number of images that are marked with a flag.
Indicates the total number of images and clips displayed on the review screen (all pages).
Images Indicates the number of images displayed on the review screen (all pages).
Indicates the number of clips displayed on all pages of the review screen.
SE Clips Stress Echo Clips
Indicates the number of stress echo clips displayed on all pages of the review screen.
Ends the current examination.
Ends the review session.
3D/4D
When a volume is the only item selected, loads the volume and displays the 3D visualization
tools.
Note: For systems without a touch screen, the selection is assigned to a soft key.
Calcs/Text
When an image or clip is the only item selected, loads the selected item to review in 1:1
format, displays the measurement menu, and provides access to the annotation menu.
Note: For systems without a touch screen, the selection is assigned to a soft key.
Changes the number of images displayed on each page.
Begins 3D data review.
To Next Page
