Touch Screen Controls
The six controls directly below the touch screen are not labeled on the control panel. In this
manual, you can identify the function assigned to the control by the text in boldface type within
brackets, as shown below.
Press or rotate [EI Color] to select a color map.
Other Controls
These controls do not have labels on the control panel. In this manual, you can identify the
function assigned to the control with descriptive text.
Slide the DGC sliders to adjust the depth gain compensation.
Roll the trackball to adjust the size of the field of view.
LED Controls
(For systems without a touch screen)
The six controls directly below the LED panel are not labelled on the control panel. In this
manual, you can identify the function assigned to the control by the text in boldface type within
brackets, as shown below.
Example Convention
Press or rotate [EI Color] to select a color map.
Soft Key Controls and Scroll Wheel
(For systems without a touch screen)
Soft key controls are located above the trackball with corresponding selections on the image
screen. In this manual, the on-screen labels are depicted with boldface type, as shown below.
Soft keys Press the
soft key.
Scroll wheel Rotate the scroll wheel to select
.
To Next Page
