Output the process image of the outputs
The following STEP 5 program sequence can be
located in any program execution level (in OB 1,
in a timed interrupt OB or in a process interrupt
OB etc.) and causes the process image of all
outputs in address list 1 to be output.
:L KB 2 Transfer function no. ’2’
:T FY 50 to FY 50
:L KB 1 Transfer address list no. ’1’
:T FY 51 to FY 51
:L KB 50 Data field begins with FY 50
:JU OB 126 Call for outputting the PIQ
: possibly evaluation of status bits
:...
OB 126: Define, Transfer Process Images
CPU 948 Programming Guide
6 - 24 C79000-G8576-C848-04
