Operation Operand Description
Table 9-11 continued:
TY CB
TY CW
TY CD
-32768 to
+32767
-32768 to
+32767
-32768 to
+32767
add the specified constant to content
of the BR register and transfer the
content of ACCU-1-LL to the byte
addressed in this way in the open page
add the specified constant to content
of the BR register and transfer the
content of ACCU-1-L to the word
addressed in this way in the open
page
add the specified constant to content
of the BR register and transfer the
content of ACCU 1 to the double
word addressed in this way in the open
page.
1)
ACCU-1-LH and ACCU-1-H are set to ’0’.
2)
ACCU-1-H is set to ’0’.
3)
ACCU 2
new
: = ACCU 1
old
Error reaction The range of absolute addresses must be
•• between F F400H and F FBFFH (LY CB, TY CB),
•• between F F400H and F FBFEH (LY CW, TY CW)
or
•• between F F400H and F FBFCH (LY CD, TY CD).
If the absolute addresses are not in the range shown, the CPU detects a
load/transfer error (TRAF) and calls OB 32. If OB 32 is not loaded,
the CPU changes to the STOP mode with the error bit TRAF
(ISTACK).
