FB 202: Sending a data field
FB 202
SEND
(1) RCPU ERWA (4)
(2) TNDB TCAP (5)
(3) FINO
Parameter
name
Significance Parameter
type
Data
type
Parameter
field
RCPU
TNDB
FINO
ERWA
TCAP
Receiving CPU
Type (H byte) and number (L byte)
of the source data block
Field number
Error/warning
Transmitting capacity
I
I
I
Q
Q
BY
W
BY
BY
BY
FY 246
FW 247
FY 249
FY 250
FY 251
FB 202 LEN=40
SEGMENT 1 0000
NAME:SEND
DECL :RCPU I/Q/D/B/T/C: I BI/BY/W/D: BY
DECL :TNDB I/Q/D/B/T/C: I BI/BY/W/D: W
DECL :FINO I/Q/D/B/T/C: I BI/BY/W/D: BY
DECL :ERWA I/Q/D/B/T/C: Q BI/BY/W/D: BY
DECL :TCAP I/Q/D/B/T/C: Q BI/BY/W/D: BY
0014 :L =RCPU Receiving CPU
0015 :T FY 246
0016 :L =TNDB DB type, DB no.
0017 :T FW 247
0018 :L =FINO Field number
0019 :T FY 249
001A :
001B :L KB 246 SF OB:
001C
:JU OB 202 "Send a data field"
001D :
001E :L FY 250 Error/warning
001F :T =ERWA
0020 :L FY 251 Transmitting capacity
0021 :T =TCAP
0022 :BE
Applications
CPU 948 Programming Guide
10 - 56 C79000-G8576-C848-04
