FB 203: Testing the transmitting capacity
FB 203
SEND-TST
(1) RCPU ERRO (2)
TCAP (3)
Parameter
name
Significance Parameter
type
Data
type
Parameter
field
RCPU
ERRO
TCAP
Receiving CPU
Error
Transmitting capacity
I
Q
Q
BY
BY
BY
FY 246
FY 248
FY 249
FB 203 LEN=30
SEGMENT 1 0000
NAME:SEND-TST
DECL :RCPU I/Q/D/B/T/C: I BI/BY/W/D: BY
DECL :ERRO I/Q/D/B/T/C: Q BI/BY/W/D: BY
DECL :TCAP I/Q/D/B/T/C: Q BI/BY/W/D: BY
000E :L =RCPU Receiving CPU
000F :T FY 246
0010 :
0011 :L KB 246 SF OB:
0012
:JU OB 203 "Test transmitting capacity"
0013 :
0014 :L FY 248 Error
0015 :T =ERRO
0016 :L FY 249 Transmitting capacity
0017 :T =TCAP
0018 :BE
Applications
CPU 948 Programming Guide
C79000-G8576-C848-04
10 - 57
