Siemens FC2005 Programming Manual

Programming Manual of FC2005/FC901
A6V10333724_b_en_-- 53|63
XTRI-M a device is added.
LED Normal Off Bool: True / False (default)
Turn Off Bool: True / False (default)
Isolator Support
When set as True, the device should be wired according to the
rules for isolator supported. Otherwise, the panel reports
trouble. When set as False (default), the device should be wired
as polar non-sensitive. Otherwise, the panel reports trouble as
well.
XTRI-R/S/D/M:
Input
Name Name of the device
Name Addition Addition description of the device; max. 20 characters
Input Closed Bool: True / False (default)
Normally Open Bool: True (default) / False
Monitoring
Option 1: Open Only (default)
Option 2: Open and short
SensorActivationDelay Range: 0.25 s (default)…240 s (select one option from the list)
XTRI-R/S/D/M:
Output channel
Name Name of the device
Name Addition Addition description of the device; max. 20 characters
Silenceable Bool: True (default) / False
Silenceable On
Waterflow
Bool: True (default) / False
Failsafe Position
Normal (default)
Off-Normal
Retain
HoldThroughReset
Device won’t be reset when press Reset button on the panel.
Bool: True / False (default)
XMS-S Name Name of the device
Name Addition Addition description of the device; max. 20 characters
Address Range: 1...50; System assigns one address automatically once
a device is added.
Turn Off Bool: True / False (default)
Isolator Support
When set as True, the device should be wired according to the
rules for isolator supported. Otherwise, the panel reports
trouble. When set as False (default), the device should be wired
as polar non-sensitive. Otherwise, the panel reports trouble as
well.
ILED-XC
ILED-XW
Name Name of the device
Name Addition Addition description of the device; max. 20 characters
Address Range: 1...50; System assigns one address automatically once
a device is added.
LED Normal Off Bool: True / False (default)
Turn Off Bool: True / False (default)
Isolator Support
When set as True, the device should be wired according to the
rules for isolator supported. Otherwise, the panel reports
trouble. When set as False (default), the device should be wired
as polar non-sensitive. Otherwise, the panel reports trouble as
