Siemens LME71 Series

18/116
Smart Infrastructure Basic Documentation LME7... CC1P7105enr
3 Type summary 24.07.2020
3 Type summary
3.1 Burner controls
Parameterized burner control for the supervision of multistage or modulating oil/gas
forced draft burners and atmospheric burners of medium to higher capacity, in
intermittent operation. With controlled air damper control.
Article no.
BPZ:LME71.000A1 BPZ:LME71.000A2 S55333-B205-A100 BPZ:LME72.000A2 *) BPZ:LME73.000A1 BPZ:LME73.000A2
Type
LME71.000A1 LME71.000A2 LME71.901A2 LME72.000A2 *) LME73.000A1 LME73.000A2
Mains voltage AC 120 V
●
--- --- ---
●
---
Mains voltage AC 230 V ---
● ● ●
---
●
Gas pressure switch-min / POC
● ● ● ● ● ●
Pressure switch valve proving
● ● ● ● ● ●
Air pressure switch
● ● ● ● ● ●
Ionization probe
● ● ● ● ● ●
QRA2 / QRA4 / QRA10
● ● ●
---
● ●
QRB1 / QRB3 / QRB4
--- --- --- ---
● ●
QRC
--- --- --- --- ---
●
Load controller analog input signal (0...10 V, 4...20 mA, 0...135 )
● ● ●
---
● ●
Load controller input 3-position step input / 2-stage
● ● ● ● ● ●
Output actuator control --- ---
---
● ● ●
Input feedback for actuator with potentiometer 0...1 k
--- --- --- ---
● ●
Output PWM control
● ● ● ● ● ●
Onboard LED 7-segment display
● ● ●
---
● ●
BC interface for AZL2
● ● ● ● ● ●
*) On request
