Smart Infrastructure Basic Documentation LME7... CC1P7105enr
4 Technical data 24.07.2020
4 Technical data
4.1 Basic unit LME7
Mains voltage AC 120 V AC 230 V
Mains frequency 50/60 Hz 50/60 Hz
External primary fuse Max. 6.3 A (slow) Max. 6.3 A (slow)
Caution!
Risk of damage to the switching contacts!
If the external primary fuse (Si) is blown due to overload or short-circuit at the
terminals, the LME7 must be replaced.
Power consumption <10 W, typical <10 W, typical
Safety class I with parts according to II and III in
accordance with DIN EN 60730-1
Degree of protection IP00
Note
The burner or boiler manufacturer must
ensure degree of protection IP40 in
accordance with DIN EN 60529 for
burner controls through adequate
installation of the LME7.
Rated surge voltage category III (DIN EN 60664)
LME7 4 kV
Creepage distances or air gaps 2.5 kV due to voltage limitation
measures
Degree of contamination 2 in accordance with DIN EN 60730-1
Software class Class C in accordance with DIN EN
60730-2-5:2011
2-channel structure
Reaction time in the event of loss of
flame
Max. 1 s
Perm. mounting position Optional
Weight Approx. 490 g
