Siemens LME71 Series

21/116
Smart Infrastructure Basic Documentation LME7... CC1P7105enr
3 Type summary 24.07.2020
3.2.2 PME7 with mains voltage AC 230 V
Article no.
BPZ:PME71.111A2 BPZ:PME71.112A2 BPZ:PME71.401A2 BPZ:PME71.402A2 BPZ:PME71.901A2 BPZ:PME72.521A2 *) BPZ:PME72.541A2 *)
Type
PME71.111A2 PME71.112A2 PME71.401A2 PME71.402A2 PME71.901A2 PME72.521A2 *) PME72.541A2 *)
Mains voltage AC 230 V
● ● ● ● ● ● ●
For use with LME71.000A2
● ● ● ● ●
--- ---
For use with LME72.000A2 --- --- --- --- ---
● ●
For use with LME73.000A2 --- --- --- --- --- --- ---
Gas program forced draft burner
●
---
● ● ● ● ●
Gas program atmospheric burner ---
●
--- --- --- --- ---
1-stage or 1-stage modulating
● ● ● ● ● ● ●
2-stage or 1-stage modulating
--- --- ● ● ● ● ●
Pilot burner simultaneously / alternately
● ●
---
●
--- ---
●
Modulating via actuator (pneumatic or mechanical fuel-air ratio control) --- --- --- --- ---
● ●
Modulating via PWM fan (pneumatic fuel-air ratio control) --- --- --- ---
●
--- ---
Fan speed control / control via analog signal / 3-position step signal --- --- --- ---
●
--- ---
Actuator control via analog signal or 3-position step signal for actuator with
ASZ
--- --- --- --- --- --- ---
3-position signal for actuator without ASZ --- --- --- --- ---
● ●
Control sequence programmable time
● ● ● ● ●
--- ---
POC
● ● ● ● ● ● ●
Valve proving --- --- --- ---
●
--- ---
Input valve proving ON/Off --- --- --- --- --- --- ---
*) Only on request
Example:
