30/116
Smart Infrastructure Basic Documentation LME7... CC1P7105enr
4 Technical data 24.07.2020
4.3 Terminal rating Outputs
Total contact loading:
Rated voltage 120 V AC, 50/60 Hz 230 V AC, 50/60 Hz
Terminal X3-04: LME7 input current Max. 5 A Max. 5 A
Note
The input current for the LME7 at terminal X3-04 pin 5 also flows through safety loop
terminal X3-04 pin 1 / pin 2.
The power supply in the LME7 to the fan motor, ignition transformer, fuel valves, and
actuators is interrupted as soon as one of the components opens the safety loop
circuit.
Individual contact loading:
Terminal X2-01 pin 3: Fan motor
Rated voltage 120 V AC, 50/60 Hz 230 V AC, 50/60 Hz
Rated current 2 A
(15 A max. 0.5 s)
2 A
(15 A for max. 0.5
s)
Power factor
Cos 0.4 Cos 0.4
Terminal X2-02 pin 3: POC/CPI or PWM fan motor (depending on the fuel train, refer
to User Documentation A7105.x)
Rated voltage 120 V AC, 50/60 Hz 230 V AC, 50/60 Hz
Total current 2 A 2 A
Power factor
Cos 0.4 Cos 0.4
Caution!
Maximum permissible current load may be exceeded!
If terminal X2-02 pin 3 is used as the connection for supplying the
PWM fan motor, no other motor may be connected on terminal X2-01
pin 3.
Terminal X2-03 pin 3: Alarm output
Rated voltage 120 V AC, 50/60 Hz 230 V AC, 50/60 Hz
Rated current 1 A 1 A
Power factor
Cos 0.6 Cos 0.6
Terminal X2-09 pin 7: Output relay contact K2/2 (auxiliary output)
Rated voltage 120 V AC, 50/60 Hz 230 V AC, 50/60 Hz
Rated current 1 A 1 A
Power factor
Cos 0.4 Cos 0.4
Terminal X3-04 pin 2: Safety loop
Rated voltage 120 V AC, 50/60 Hz 230 V AC, 50/60 Hz
Total current 2 A 2 A
Power factor
Cos 0.4 Cos 0.4
Terminal X4-02 pin 3: Ignition transformer
Rated voltage 120 V AC, 50/60 Hz 230 V AC, 50/60 Hz
Rated current 2 A 2 A
Power factor
Cos 0.4 Cos 0.4
