2 Installation
MICROMASTER 430 Operating Instructions
6SE6400-5AC00-0BP0
23
2.3 Mechanical installation
WARNING
♦ To ensure the safe operation of the equipment, it must be installed and
commissioned by qualified personnel in full compliance with the warnings laid
down in these operating instructions.
♦ Take particular note of the general and regional installation and safety
regulations regarding work on dangerous voltage installations (e.g. EN
50178), as well as the relevant regulations regarding the correct use of tools
and personal protective equipment (PPE).
♦ The mains input, DC and motor terminals, can carry dangerous voltages even
if the inverter is inoperative; wait 5 minutes to allow the unit to discharge after
switching off before carrying out any installation work.
♦ The inverters may only be fitted side by side. The following clearances above
and below the inverter are necessary:
Ø FS C 100 m
Ø FS D, E300 mm
Ø FS F 350 mm
♦ When mounting one inverter above the other, the ambient operating
temperature must be adhered to.
4
Table 2-1 Dimensions and Torques of MICROMASTER 430
Frame-Size Overall Dimensions Fixing Method
Tightening
Torque
mm 185 x 245 x 195
C
Width x
Height x
Depth
inch 7.28 x 9.65 x 7.68
4 x M5 Bolts
4 x M5 Nuts
4 x M5 Washers
2.5 Nm
with washers fitted
mm 275 x 520 x 245
D
Width x
Height x
Depth
inch 10.82 x 20.47 x 9.65
4 x M8 Bolts
4 x M8 Nuts
4 x M8 Washers
3.0 Nm
with washers fitted
mm 275 x 650 x 245
E
Width x
Height x
Depth
inch 10.82 x 25.59 x 9.65
4 x M8 Bolts
4 x M8 Nuts
4 x M8 Washers
3.0 Nm
with washers fitted
mm
350 x 850 mm x 320
height with filter 1150
F
Width x
Height x
Depth
inch
13.78 x 33.46 x 12.60
height with filter 45.28
4 x M8 Bolts
4 x M8 Nuts
4 x M8 Washers
3.0 Nm
with washers fitted
