Siemens MICROMASTER 430 Manual

6 Troubleshooting
MICROMASTER 430 Operating Instructions
6SE6400-5AC00-0BP0
75
6.2 Troubleshooting with the BOP-2
Warnings and faults are displayed on the BOP-2 with Axxx and Fxxx respectively.
The individual messages are shown in Section 6.3.
If the motor fails to start when the ON command has been given:
Ø Check that P0010 = 0.
Ø Check that a valid ON signal is present.
Ø Check that P0700 = 2 (for digital input control) or
P0700 = 1 (for BOP-2 control).
Ø Check that the setpoint is present (0 to 10V on Terminal 3) or the setpoint has
been entered into the correct parameter, depending upon the setpoint source
(P1000). See the Parameter List for further details.
If the motor fails to run after changing the parameters, set P0010 = 30 then P0970
= 1 and press P to reset the inverter to the factory default parameter values.
Now use a switch between terminals 5 and 8 on the control board. The drive
should now run to the defined setpoint by analogue input.
NOTICE
Motor data must relate to the inverter data power range and voltage.
www.eltra-trade.com
+421 552 601 099
info@eltra-trade.com

Siemens MICROMASTER 430 Specifications

General

Power Range	7.5 kW to 250 kW
Voltage Range	380V to 480V
Frequency Range	0 Hz to 650 Hz
Protection Class	IP20
Input Frequency	47 Hz to 63 Hz
Digital Inputs	6
Cooling Method	Forced-air cooling
Communication	USS
Protection Features	Overvoltage, undervoltage, overcurrent, short-circuit, ground fault, overtemperature
Analog Inputs	2
Digital Outputs	3
Analog Outputs	2
Ambient Temperature	-10°C to +50°C
Control Type	Sensorless vector control
