Siemens MICROMASTER 430 Manual

5 System parameters
MICROMASTER 430 Operating Instructions
62 6SE6400-5AC00-0BP0
Encoder (P0004 = 4)
ParNr ParText Default Level DS QC
P0400[3] Select encoder type 0 3 CT N
P0408[3] Encoder pulses per revolution 1024 3 CT N
P0492[3] Allowed speed difference 10.00 3 CT N
P0494[3] Delay speed loss reaction 10 3 CUT N
Technological Functions (P0004 = 5)
ParNr ParText Default Level DS QC
P0500[3] Technological application 0 3 CT Q
Commands and Digital I/O (P0004 = 7)
ParNr ParText Default Level DS QC
r0002 Drive state - 3 - -
r0019 CO/BO: BOP control word - 3 - -
r0050 CO: Active command data set - 2 - -
r0052 CO/BO: Act. status word 1 - 3 - -
r0051[2] CO: Active drive data set (DDS) - 2 - -
r0053 CO/BO: Act. status word 2 - 3 - -
r0054 CO/BO: Act. control word 1 - 3 - -
r0055 CO/BO: Add. act. control word - 3 - -
r0403 CO/BO: Encoder status word - 3 - -
P0700[3] Selection of command source 2 1 CT Q
P0701[3] Function of digital input 1 1 2 CT N
P0702[3] Function of digital input 2 12 2 CT N
P0703[3] Function of digital input 3 9 2 CT N
P0704[3] Function of digital input 4 15 2 CT N
P0705[3] Function of digital input 5 15 2 CT N
P0706[3] Function of digital input 6 15 2 CT N
P0707[3] Function of digital input 7 0 3 CT N
P0708[3] Function of digital input 8 0 3 CT N
P0718 CO/BO: Hand / Auto 0 3 CUT N
r0720 Number of digital inputs - 3 - -
P0719[3] Selection of cmd. & freq. setp. 0 3 CT N
r0722 CO/BO: Binary input values - 3 - -
P0724 Debounce time for digital inputs 3 3 CT N
P0725 PNP / NPN digital inputs 1 3 CT N
r0730 Number of digital outputs - 3 - -
P0731[3] BI: Function of digital output 1 52:3 2 CUT N
P0732[3] BI: Function of digital output 2 52:7 2 CUT N
P0733[3] BI: Function of digital output 3 0:0 2 CUT N
r0747 CO/BO: State of digital outputs - 3 - -
P0748 Invert digital outputs 0 3 CUT N
P0800[3] BI: Download parameter set 0 0:0 3 CT N
P0801[3] BI: Download parameter set 1 0:0 3 CT N
P0810 BI: CDS bit 0 (Local / Remote) 718:0 3 CUT N
www.eltra-trade.com
+421 552 601 099
info@eltra-trade.com

Siemens MICROMASTER 430 Specifications

General

Power Range	7.5 kW to 250 kW
Voltage Range	380V to 480V
Frequency Range	0 Hz to 650 Hz
Protection Class	IP20
Input Frequency	47 Hz to 63 Hz
Digital Inputs	6
Cooling Method	Forced-air cooling
Communication	USS
Protection Features	Overvoltage, undervoltage, overcurrent, short-circuit, ground fault, overtemperature
Analog Inputs	2
Digital Outputs	3
Analog Outputs	2
Ambient Temperature	-10°C to +50°C
Control Type	Sensorless vector control
