Siemens MICROMASTER 430 Manual

5 System parameters
MICROMASTER 430 Operating Instructions
6SE6400-5AC00-0BP0
63
ParNr ParText Default Level DS QC
P0811 BI: CDS bit 1 0:0 2 CUT N
P0809[3] Copy command data set (CDS) 0 3 CT N
P0820 BI: DDS bit 0 0:0 3 CT N
P0821 BI: DDS bit 1 0:0 3 CT N
P0819[3] Copy drive data set (DDS) 0 2 CT N
P0840[3] BI: ON/OFF1 722:0 3 CT N
P0842[3] BI: ON reverse/OFF1 0:0 3 CT N
P0844[3] BI: 1. OFF2 1:0 3 CT N
P0845[3] BI: 2. OFF2 19:1 3 CT N
P0848[3] BI: 1. OFF3 1:0 3 CT N
P0849[3] BI: 2. OFF3 1:0 3 CT N
P0852[3] BI: Pulse enable 1:0 3 CT N
P1020[3] BI: Fixed freq. selection Bit 0 0:0 3 CT N
P1021[3] BI: Fixed freq. selection Bit 1 0:0 3 CT N
P1022[3] BI: Fixed freq. selection Bit 2 0:0 3 CT N
P1023[3] BI: Fixed freq. selection Bit 3 722:3 3 CT N
P1026[3] BI: Fixed freq. selection Bit 4 722:4 3 CT N
P1028[3] BI: Fixed freq. selection Bit 5 722:5 3 CT N
P1035[3] BI: Enable MOP (UP-command) 19:13 3 CT N
P1036[3] BI: Enable MOP (DOWN-command) 19:14 3 CT N
P1074[3] BI: Disable additional setpoint 0:0 3 CUT N
P1110[3] BI: Inhibit neg. freq. setpoint 1:0 3 CT N
P1113[3] BI: Reverse 722:1 3 CT N
P1140[3] BI: RFG enable 1:0 3 CT N
P1141[3] BI: RFG start 1:0 3 CT N
P1142[3] BI: RFG enable setpoint 1:0 3 CT N
P1230[3] BI: Enable DC braking 0:0 3 CUT N
P1270[3] BI: Enable essential service 0:0 3 CUT N
P2103[3] BI: 1. Faults acknowledgement 722:2 3 CT N
P2104[3] BI: 2. Faults acknowledgement 0:0 3 CT N
P2106[3] BI: External fault 1:0 3 CT N
P2220[3] BI: Fixed PID setp. select Bit 0 0:0 3 CT N
P2221[3] BI: Fixed PID setp. select Bit 1 0:0 3 CT N
P2222[3] BI: Fixed PID setp. select Bit 2 0:0 3 CT N
P2223[3] BI: Fixed PID setp. select Bit 3 722:3 3 CT N
P2226[3] BI: Fixed PID setp. select Bit 4 722:4 3 CT N
P2228[3] BI: Fixed PID setp. select Bit 5 722:5 3 CT N
P2235[3] BI: Enable PID-MOP (UP-cmd) 19:13 3 CT N
P2236[3] BI: Enable PID-MOP (DOWN-cmd) 19:14 3 CT N
Analogue I/O (P0004 = 8)
ParNr ParText Default Level DS QC
P0295 Inverter fan off delay time 0 3 CUT N
r0750 Number of ADCs - 3 - -
r0752[2] Act. input of ADC [V] or [mA] - 2 - -
