Siemens MICROMASTER 430 Manual

5 System parameters
MICROMASTER 430 Operating Instructions
64 6SE6400-5AC00-0BP0
ParNr ParText Default Level DS QC
P0753[2] Smooth time ADC 3 3 CUT N
r0754[2] Act. ADC value after scaling [%] - 2 - -
r0755[2] CO: Act. ADC after scal. [4000h] - 3 - -
P0756[2] Type of ADC 0 2 CT N
P0757[2] Value x1 of ADC scaling [V / mA] 0 2 CUT N
P0758[2] Value y1 of ADC scaling 0.0 2 CUT N
P0759[2] Value x2 of ADC scaling [V / mA] 10 2 CUT N
P0760[2] Value y2 of ADC scaling 100.0 2 CUT N
P0761[2] Width of ADC deadband [V / mA] 0 3 UT N
P0762[2] Delay for loss of signal action 10 3 CUT N
r0770 Number of DACs - 3 - -
P0771[2] CI: DAC 21:0 2 CUT N
P0773[2] Smooth time DAC 2 3 CUT N
r0774[2] Act. DAC value [V] or [mA] - 3 - -
P0776[2] Type of DAC 0 2 CT N
P0777[2] Value x1 of DAC scaling 0.0 2 CUT N
P0778[2] Value y1 of DAC scaling 0 2 CUT N
P0779[2] Value x2 of DAC scaling 100.0 2 CUT N
P0780[2] Value y2 of DAC scaling 20 2 CUT N
P0781[2] Width of DAC deadband 0 3 CUT N
Setpoint Channel and Ramp Generator (P0004 = 10)
ParNr ParText Default Level DS QC
P1000[3] Selection of frequency setpoint 2 1 CT Q
P1001[3] Fixed frequency 1 0.00 3 CUT N
P1002[3] Fixed frequency 2 5.00 3 CUT N
P1003[3] Fixed frequency 3 10.00 3 CUT N
P1004[3] Fixed frequency 4 15.00 3 CUT N
P1005[3] Fixed frequency 5 20.00 3 CUT N
P1006[3] Fixed frequency 6 25.00 3 CUT N
P1007[3] Fixed frequency 7 30.00 3 CUT N
P1008[3] Fixed frequency 8 35.00 3 CUT N
P1009[3] Fixed frequency 9 40.00 3 CUT N
P1010[3] Fixed frequency 10 45.00 3 CUT N
P1011[3] Fixed frequency 11 50.00 3 CUT N
P1012[3] Fixed frequency 12 55.00 3 CUT N
P1013[3] Fixed frequency 13 60.00 3 CUT N
P1016 Fixed frequency mode - Bit 0 1 3 CT N
P1014[3] Fixed frequency 14 65.00 3 CUT N
P1017 Fixed frequency mode - Bit 1 1 3 CT N
P1015[3] Fixed frequency 15 65.00 3 CUT N
P1018 Fixed frequency mode - Bit 2 1 3 CT N
P1019 Fixed frequency mode - Bit 3 1 3 CT N
r1024 CO: Act. fixed frequency - 3 - -
P1025 Fixed frequency mode - Bit 4 1 3 CT N
www.eltra-trade.com
+421 552 601 099
info@eltra-trade.com

Siemens MICROMASTER 430 Specifications

General

Power Range	7.5 kW to 250 kW
Voltage Range	380V to 480V
Frequency Range	0 Hz to 650 Hz
Protection Class	IP20
Input Frequency	47 Hz to 63 Hz
Digital Inputs	6
Cooling Method	Forced-air cooling
Communication	USS
Protection Features	Overvoltage, undervoltage, overcurrent, short-circuit, ground fault, overtemperature
Analog Inputs	2
Digital Outputs	3
Analog Outputs	2
Ambient Temperature	-10°C to +50°C
Control Type	Sensorless vector control
