5 System parameters
MICROMASTER 430 Operating Instructions
6SE6400-5AC00-0BP0
65
ParNr ParText Default Level DS QC
P1027 Fixed frequency mode - Bit 5 1 3 CT N
P1032 Inhibit reverse direction of MOP 1 3 CT N
P1031[3] Setpoint memory of the MOP 0 3 CUT N
P1040[3] Setpoint of the MOP 5.00 2 CUT N
r1050 CO: Act. Output freq. of the MOP - 3 - -
P1070[3] CI: Main setpoint 755:0 3 CT N
P1071[3] CI: Main setpoint scaling 1:0 3 CT N
P1075[3] CI: Additional setpoint 0:0 3 CT N
r1078 CO: Total frequency setpoint - 3 - -
P1076[3] CI: Additional setpoint scaling 1:0 3 CT N
P1080[3] Min. frequency 0.00 1 CUT Q
P1082[3] Max. frequency 50.00 1 CT Q
P1091[3] Skip frequency 1 0.00 3 CUT N
P1092[3] Skip frequency 2 0.00 3 CUT N
P1093[3] Skip frequency 3 0.00 3 CUT N
P1094[3] Skip frequency 4 0.00 3 CUT N
P1101[3] Skip frequency bandwidth 2.00 3 CUT N
r1114 CO: Freq. setp. after dir. ctrl. - 3 - -
r1119 CO: Freq. setpoint before RFG - 3 - -
P1120[3] Ramp-up time 10.00 1 CUT Q
P1121[3] Ramp-down time 30.00 1 CUT Q
P1130[3] Ramp-up initial rounding time 0.00 2 CUT N
P1131[3] Ramp-up final rounding time 0.00 2 CUT N
P1132[3] Ramp-down initial rounding time 0.00 2 CUT N
P1133[3] Ramp-down final rounding time 0.00 2 CUT N
P1134[3] Rounding type 0 2 CUT N
P1135[3] OFF3 ramp-down time 5.00 2 CUT Q
r1170 CO: Frequency setpoint after RFG - 3 - -
Drive Features (P0004 = 12)
ParNr ParText Default Level DS QC
P0005[3] Display selection 21 2 CUT N
P0006 Display mode 2 3 CUT N
P0007 Backlight delay time 0 3 CUT N
P0011 Lock for user defined parameter 0 3 CUT N
P0012 Key for user defined parameter 0 3 CUT N
P0013[20] User defined parameter 0 3 CUT N
P1200 Flying start 0 3 CUT N
P1202[3] Motor-current: Flying start 100 3 CUT N
P1203[3] Search rate: Flying start 100 3 CUT N
P1210 Automatic restart 1 3 CUT N
P1211 Number of restart attempts 3 3 CUT N
P1212 Time to first restart 30 3 CUT N
P1213 Restart time increment 30 3 CUT N
P1215 Holding brake enable 0 2 T N
