Siemens MICROMASTER 430 Manual

6 Troubleshooting
MICROMASTER 430 Operating Instructions
78 6SE6400-5AC00-0BP0
Fault Possible Causes Diagnose & Remedy Reac
tion
F0041
Motor Data
Identification
Failure
Motor data identification failed.
Alarm value =0: Load missing
Alarm value =1: Current limit level
reached during identification.
Alarm value =2: Identified stator
resistance less than 0.1% or
greater than 100%.
Alarm value =3: Identified
rotorresistance less than 0.1% or
greater than 100%.
Alarm value =4: Identified stator
reactance less than 50% and
greater than 500%
Alarm value =5: Identified main
reactance less than 50% and
greater than 500%
Alarm value =6: Identified rotor time
constant less than 10ms or
greater than 5s
Alarm value =7: Identified total
leakage reactance less than 5%
and greater than 50%
Alarm value =8: Identified stator
leakage reactance less than 25%
and greater than 250%
Alarm value =9: Identified rotor
leakage inductance less than
25% and greater than 250%
Alarm value = 20: Identified IGBT on-
voltage less than 0.5 or greater
than 10V
Alarm value = 30: Current controller
at voltage limit
Alarm value = 40: Inconsistence of
identified data set, at least one
identification failed
Percentage values based on the
impedance Zb = Vmot,nom / sqrt(3) /
Imot,nom
0: Check that the motor is connected to the
inverter.
1-40: Check if motor data in P304-311 are correct.
Check what type of motor wiring is required (star,
delta).
Off1
F0051
Parameter
EEPROM Fault
Read or write failure while saving
non-volatile parameter.
1. Factory Reset and new parameterization
2. Change drive
Off1
F0052
power stack
Fault
Read failure for power stack
information or invalid data.
Change drive Off1
F0053
IO Eeprom
Fault
Read failure for IO EEPROM
information or invalid data.
1. Check data
2. Change IO module
Off1
F0054
Wrong IO
Board
Ø Wrong IO board is connected.
Ø No ID detected on IO board, No
data.
1. Check data
2. Change IO module
Off1
F0060
Asic Timeout
Internal communications failure
1. If fault persists, change inverter,
2. Contact Service Department
Off1
F0070
CB setpoint
fault
No setpoint values from CB
(communication board) during
telegram off time
Check CB and communication partner Off1
www.eltra-trade.com
+421 552 601 099
info@eltra-trade.com

Siemens MICROMASTER 430 Specifications

General

Power Range	7.5 kW to 250 kW
Voltage Range	380V to 480V
Frequency Range	0 Hz to 650 Hz
Protection Class	IP20
Input Frequency	47 Hz to 63 Hz
Digital Inputs	6
Cooling Method	Forced-air cooling
Communication	USS
Protection Features	Overvoltage, undervoltage, overcurrent, short-circuit, ground fault, overtemperature
Analog Inputs	2
Digital Outputs	3
Analog Outputs	2
Ambient Temperature	-10°C to +50°C
Control Type	Sensorless vector control
