Mounting
4.4 Mounting and connecting
MicroSAM
Operating Instructions, 06/2012, C79000-G5376-C560-07
69
2. Carefully rotate the 1.5 mm hexagon socket-head bolt ② in the ring in the clockwise
direction as far as possible.
