Service and maintenance
6.3 Installing and removing electronic components
MicroSAM
90 Operating Instructions, 06/2012, C79000-G5376-C560-07
Removing the RSP module
Procedure
1. Disconnect all electric connections.
2. Loosen the six screws
① T30.
3. Carefully remove the RSP module
②.
