Service and maintenance
6.3 Installing and removing electronic components
MicroSAM
Operating Instructions, 06/2012, C79000-G5376-C560-07
91
Removing the EPC module
Procedure
1. Loosen the three connectors
①.
2. Loosen the four screws T10
②.
3. Carefully remove the EPC module
③.
