Siemens MOBILETT Plus HP Service Manual

Mechanical systems 10 - 5
Siemens AG SPR8-220.061.03 Page 5 of 28 MOBILETT Plus HP
Medical Solutions Rev. 03 09.03 CS PS 24
Movement of the fork
If the fork does not hold its position, it must be adjusted (Fig. 7).
• Loosen the screw completely.
• Retighten the screw until there is no play.
• Tighten the screw until the fork holds its position.
Movement of the single tank
If the single tank rotates too easily or does not hold its position in the fork:
• Remove the caps on the fork.
• Tighten or loosen the friction adjustment (one on each side of the fork) (Fig. 8).
Fig. 7 Fig. 8
MOB00466
MOB00580
