Final assembly work
110-0084.9 / 15 NXAIR / ≤ 40 kA 201
12.3 In panels without ventilation duct: Check the floor fixing in the switching-device compartment
Bolted floor fixing:
Check the bolted joint of the floor fixing in the switching-device compartment at
random with the torque wrench.
Check the corrosion protection of the floor fixing in the switching-device compartment
at random.
12.4 Checking the panel connection links
At the front of all panels, check the installation of the panel connection link between
the switching-device compartments.
12.5 Checking the installation of the wiring duct covers
Check the installation of the wiring duct covers on the left inside of the panel (only for
contactor panels with panel width 435 mm on the right inside).
12.6 Checking control cable connections
Check the following screw-type connections of control cables:
Perform random checks of the control cable connections on devices and terminal blocks.
Check all control cable connections of current transformer terminals in the low-voltage
compartment (including slides and jumpers).
If there are any terminal blocks without labels, complete labels using the information
given in the circuit diagrams.
12.7 Checking the vertical partition between the switching-device compartment and the connection
compartment
Check all bolted joints all around with the torque wrench.
12.8 Checking the rear wall at the connection compartment
Check all bolted joints at the ledges of the rear wall with the torque wrench.
12.9 Checking the bushings
Sharp edges
Mechanical parts may have sharp edges.
Do not reach into the right-hand and left-hand shutter mechanism in the
switching-device compartment.
Do not reach into the shutters in front of the bushings.
Do not operate the shutters in front of the bushings manually.
Do only open and close the shutters with the corresponding shutter levers,
see Operating Instructions with order number 110-0134.9.
