Siemens PCS 7 - Configuration Tables; Configurations with Engineering Station, Clients and Single Station System

Notes for the reader on the tables below
Note
Read Tables 1 - 3 carefully from left to right. This means that a PC with a standard installation
can also be used for an additional purpose (by using properties or an additional installation by
means of the PCS 7 system setup).
Example:
If you also use a PC station with the standard configuration "engineering station" as an "OS
single station system", the notes and restrictions defined under "A" (configuration type "A") will
apply.
Notes and restrictions:
You can find information on this in the following sections:
● Section "Information on configuration type "X" (Page 148)"
● Section "Information on configuration type "-" (Page 149)"
● Section "Information on configuration type "A" (Page 149)"
● Section "Information on configuration type "B" (Page 149)"
6.2.2 Configuration tables
6.2.2.1 Configurations with engineering station, clients and single station system
Table 1 – Configurations with Engineering Station, Clients and Single Station System
Purpose Engineering
station
OS
single-station
system
OS
client
BATCH single
station system
BATCH
client
Route Control
single station
system
Route
Control
Client
Standard config‐
uration
Engineering sta‐
tion
A (Page 149) B
(Page
149)
--- (Page 149) X
(Page
148)
--- (Page 149) X
(Page
148)
OS
single-station
system
--- (Page 149) ---
(Page
149)
X (Page 148) X
(Page
148)
X (Page 148) X
(Page
148)
OS client --- (Page 149) --- (Page 149) X (Page 148) X
(Page
148)
X (Page 148) X
(Page
148)
BATCH single
station system
--- (Page 149) X (Page 148) X
(Page
148)
---
(Page
149)
X (Page 148) ---
(Page
149)
BATCH Client --- (Page 149) --- (Page 149) X
(Page
148)
--- (Page 149) --- (Page 149) X
(Page
148)
