3.28 Displays
SCALANCE X-200
Operating Instructions, 12/2011, A5E00349864-19
125
3.28.5 Standby functions (yellow LED)
Standby functions (yellow LED)
The LED signals that the IE Switch X-200IRT can adopt the following statuses:
Device type SCALANCE LED lit yellow LED flashes yellow
(slowly)
LED flashes yellow
(fast)
LED not lit
XF204 - - - -
X208 - - - -
XF208 - - - -
X216 - - - -
X224 - - - -
X204-2 - - - -
X204-2TS - - - -
XF204-2 - - - -
X206-1 - - - -
XF206-1 - - - -
X212-2 - - - -
X204-2LD - - - -
X206-1LD - - - -
X212-2LD - - - -
X202-2IRT 1 2 3 4
X204IRT 1 2 3 4
XF204IRT 1 2 3 4
X204 IRT PRO 1 2 3 4
X202-2P IRT PRO 1 2 3 4
X201-3P IRT PRO 1 2 3 4
X202-2P IRT 1 2 3 4
X201-3P IRT 1 2 3 4
X200-4P IRT 1 2 3 4
1. Standby function is enabled (IE Switch X-200 is in standby active mode).
2. Standby function is enabled (IE Switch X-200 is in standby passive mode).
