Product properties
3.17 SCALANCE X202-2IRT
SCALANCE X-200
Operating Instructions, 12/2011, A5E00349864-19
85
3.17 SCALANCE X202-2IRT
3.17.1 SCALANCE X202-2IRT product characteristics
Possible attachments
The SCALANCE X202-2IRT has two RJ-45 jacks and two BFOC ports for the connection of
end devices or other network segments.
Note
The BFO
C socket (Bayonet Fiber Optic Connector) corresponds to the ST socket.
Figure 3-27 SCALANCE X202-2IRT
